WS-X4748-UPOE+E Cisco Catalyst 4500 Series Line Card

Product Attributes :

Product Code	WS-X4748-UPOE+E
Line-Card Type	Cisco Catalyst 4500E Series 10/100/1000/Multigigabit Line Cards
UPOE	capable of up to 60 W per port up to 1440 W
Chassis Support	4503-E/4506-E/4507R+E/4510R+E/4507R-E/4510R-E
Supervisor Support	7L-E/7-E/8-E
Per-slot capacity	Up to 48 Gbps
Ports	48 * 10/100/1000 Gigabit nonblocking Ethernet UPOE ports
Module	10/100/1000 module (RJ-45)
Cisco IOS XE	Cisco IOS XE Release 3.2.0SG or later
Max Rated Power (W)	75
Rated MTBF (Hours)	140,696
Hardware	Cisco TrustSec capability in hardware
Enterprise and commercial	designed to power next-generation IP phones, wireless base stations, video cameras, virtual desktop clients, and other PoE/UPOE devices
Energy Efficient Ethernet	Energy Efficient Ethernet 802.3az
Inline power	Capable of up to 30 W of inline power per port on all ports simultaneously
Flow control	IEEE 802.3af/at and Cisco prestandard PoE, IEEE 802.3x flow control
L2-4 Jumbo Frame support	up to 9216 bytes

Product Description

WS-X4748-UPOE+E Specifications
Port Information
Type	E-Series 10/100/1000/Multigigabit Line Cards
Number of Ports	48
Port Speed	10/100/1000
Port Type	RJ-45 UPOE IEEE 802.3at, IEEE 802.3af, Cisco prestandard
Wire Rate	1:1
Feature
Standards	● Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 803.3at, IEEE 802.3af, IEEE 802.3az ● 1000BASE-X (GBIC), 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-ZX, CWDM
EtherChannel Technology	● Gigabit EtherChannel: All 1000 Mbps ports ● 10 Gigabit EtherChannel: All 10Gbps ports ● IEEE 802.3ad (Link Aggregation Control Protocol): All 1000 Mbps ports ● Port Aggregation Protocol (PagP): Yes ● Number of ports per tuple: 8 ● EtherChannel and IEEE 802.3ad technology across line cards: Yes
Physical Dimensions	● Occupies one slot in the Cisco Catalyst 4500 Series platform ● Dimensions (H x W x D): 1.2 x 14.25 x 10.75 in. (3.0 x 36.2 x 27.3 cm)
Environmental Conditions	● Operating temperature: 32° to 104°F (0° to 40°C) ● Storage temperature: -40° to 167°F (-40° to 75°C) ● Relative humidity: 10 to 90%, noncondensing ● Operating altitude: -60 to 3000m
Safety Conditions	Fiber optic lasers: Class 1 laser products
Safety Certifications	● UL 1950 ● EN 60950 ● CSA-C22.2 no 950 ● IEC 950 ● IEC 60950-1, 2nd Ed. EN 60950-1, 2nd Ed. UL 60950-1, 2nd Ed. CAN/CSA-C22.2 No. 60950-1 2nd Ed.11
Electromagnetic Emissions Certifications	● FCC 15J Class A ● VCCI Class A ● CE Marking ● EN 55022 Class A ● EN 55024 Class A ● CISPR 22 Class A ● AS/NZ 3548 ● NEBS Level 3 (GR-1089-CORE, GR-63-CORE) ● ETSI ETS-300386-2 ● EN 50121-4
ROHS Compliance	ROHS5
Power and MTBF Information
Max Rated Power (W)	75
Rated MTBF (Hours)	140,696
