Brand New Fortinet FortiGate 100E firewall FG-100E
Brand New Fortinet FortiGate 100E firewall FG-100E Brand New Fortinet FortiGate 100E firewall FG-100E Brand New Fortinet FortiGate 100E firewall FG-100E

Brand New Fortinet FortiGate 100E firewall FG-100E

Product Attributes :
Overview
Quick Details

  • Products Status:

  • Stock

  • Type:

  • Wired

  • VPN Support:

  • Yes

  • Throughput:

  • 7.4 Gbps

  • Simultaneous Sessions:

  • 300

  • Certification:

  • CE RoHS FCC

  • Brand Name:

  • Fortinet

  • Model Number:

  • FG-100E

  • Place of Origin:

  • Guangdong, China

  • Product name:

  • FortiGate 100E

  • Warranty:

  • 1 Year

  • Dimensions:

  • 44.45 x 432 x 254 mm

  • Weight:

  • 7.28 lbs (3.3 kg)


Product Description
Specification
Hardware Specifications
GE RJ45 Ports
14
GE RJ45 Management/HA/DMZ Ports
1 / 2 / 1
GE SFP Slots
-
GE RJ45 PoE/+ Ports
-
GE RJ45 WAN Ports
2
GE RJ45 or SFP Shared Ports
2
USB Port
1
Console Port
1
Internal Storage
-
Included Transceivers
0
System Performance - Enterprise Traffic Mix
IPS Throughput 2
500 Mbps
NGFW Throughput 2, 4
360 Mbps
Threat Protection Throughput 2, 5
250 Mbps
System Performance
Firewall Throughput
7.4 / 7.4 / 4.4 Gbps
Firewall Latency (64 byte UDP packets)
3 μs
Firewall Throughput (Packets Per Second)
6.6 Mpps
Concurrent Sessions (TCP)
2 Million
New Sessions/Second (TCP)
30,000
Firewall Policies
10,000
IPsec VPN Throughput (512 byte)
4 Gbps
Gateway-to-Gateway IPsec VPN Tunnels
2,000
Client-to-Gateway IPsec VPN Tunnels
10,000
SSL-VPN Throughput
250 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)
300
SSL Inspection Throughput (IPS, avg. HTTPS) 3
130 Mbps
SSL Inspection CPS (IPS, avg. HTTPS) 3
130
SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3
125,000
Application Control Throughput (HTTP 64K) 2
1 Gbps
CAPWAP Throughput (HTTP 64K)
1.5 Gbps
Virtual Domains (Default / Maximum)
10 / 10
Maximum Number of Switches Supported
24
Maximum Number of FortiAPs (Total / Tunnel Mode)
64 / 32
Maximum Number of FortiTokens
1,000
Maximum Number of Registered FortiClients
600
High Availability Configurations
Active / Active, Active / Passive, Clustering
Dimensions
Height x Width x Length (inches)
1.75 x 17 x 10
Height x Width x Length (mm)
44.45 x 432 x 254
Form Factor
Rack Mount, 1 RU
Weight
7.28 lbs (3.3 kg)
Environment
Power Required
100–240V AC, 50–60 Hz
Maximum Current
100V / 1A, 240V / 0.5A
Total Available PoE Power Budget*
